Horizontal 380V 50/60Hz Facial Mask Filling And Packaging Machine

Place of Origin: CHINA
Brand Name: HIJ/TRUSTAR
Certification: CE
Model Number: VPD-200
Product Details
Place of Origin:
CHINA
Brand Name:
HIJ/TRUSTAR
Certification:
CE
Model Number:
VPD-200
Minimum Order Quantity:
1
Price:
Negotiable
Standard Packaging:
Seathworthy wooden cases
Delivery Time:
It depends.
Payment Terms:
T/T
Supply Ability:
It depends.
Specifications
Packing speed:
40-60 Bags/minute
Bag size:
L:80-20mm W:100-200mm
Bag type:
Square, Rectangular And Parts Of Irregular Shape Bag
Add liquid range:
3-30ml, Precision±0.5ml
Weight:
1000kg
Voltage:
380v 50/60hz
Highlight:

mask making machine

,

mask manufacturing machine

Product Description



Horizontal 380V 50/60Hz Facial Mask Filling And Packaging Machine

VPD200 Horizontal Type Giving Bag Packing Machine





Functions:

Putting the premade bags in the bag box→ Robort arm pick the bag one by one→ open the bag(the machine will automatic tracking those bags which not opened, these bags can be collected and used again)→Bag top side Sealing→ Embossing date/batch(Max 35 characters)→Conveyor belt transport the finished bag.



Main Features

It is suitable for quantitative packaging of mask, wet towel, granule , powder and other objects. Automatic feeding, metering, filling and sealing, printing date, the whole process of conveying and discharging. It has high precision and efficiency. The sealing is firm, smooth and beautiful. Suitable for kinds of specifications prefabricated bags, such as four side sealing bags, special-shape bags, self-supporting bags, etc.





Main Technical Parameter
Item/model Model:VPD200 Horizontal Type Giving Bag Packing Machine
Packing material Heat sealable PET, OPP,BOPP /AL/ PE, CPP laminate film.
Bag Size L:80-200mm , W:100-200mm (L*W)
Bag shape

Square bag, rectangular bag and parts of irregular shape bag
Add liquid range 3-30ml Essence Fluid ; precision ±0.5ml ;the coefficient of viscosity should under the 20000(cp)
Produce speed 40-60 bags/min
Power supply Three-phases four wires 380V 50/60Hz 3.5Kw
Weight 1000KG
Machine Size About 2450mm×1080mm×1800mm (L*W*H)
Air pressure 0.6-1.0Mpa Consumption＞0.4m³/min







Horizontal 380V 50/60Hz Facial Mask Filling And Packaging Machine

Horizontal 380V 50/60Hz Facial Mask Filling And Packaging MachineHorizontal 380V 50/60Hz Facial Mask Filling And Packaging MachineHorizontal 380V 50/60Hz Facial Mask Filling And Packaging Machine
