Product Details:
|
| Mixer Type: | Homogenizer | Material Processed: | Chemicals, Food, Medicine |
|---|---|---|---|
| Product Type: | Cosmetic,Cream, Shampoo,Gel, Soap | Range Of Spindle Speed(r.p.m): | 0 - 3500 R.p.m |
| Application: | Viscous Fluid | Voltage: | 220V/380V 50HZ |
| Function: | Vacuum Emulsifying Mixer | Applicable Industries: | Manufacturing Plant, Food & Beverage Factory, Cosmetics |
| Highlight: | Blends Cream Vacuum Emulsifier Mixer,Vacuum Emulsifier Mixer 3500 r.p.m,380V Vacuum Emulsifier Mixer |
||
string sachet powder seasoning powder spice flour horizontal packing machine for flat bag
The packaging machine can can complete pouch forming, feeding, measuring, filling, sealing, date printing, nitrogen filling, counting, finished product delivery. It is suitable for filling different products such as powder, granule, tablets, liquid, cream and other non free-flowing liquid when equipped with feeding and measuring devices.
Machine parameters
| operation | HFFS | Horizontal form fill and seal | |
| Technology concept | Pouch forming | Form the reel | |
| Pouch transport system | intermittent | ||
| Construction | Machine frame | SS304 and carbon steel | |
| parts | SS304 and aluminum alloy | ||
| Parts in contact with product | Stainless steel SUS316 | ||
| Reel | Reel diameter | 400mm | |
| Reel Width | 4400mm | ||
| Reel core | 76mm | ||
| dimensions | Length×width×height | 2850*970*1250mm | |
| weight | 1000Kg | ||
| Pouch dimensions | Length×width×height | Minimum size | Maximum size |
| 60*80mm | 160*200mm | ||
| speed(ppm) volume(c.c) |
Speed max | Volume max | |
| 60-85 bag per mintue | 160ml | ||
| Consumption | Electrical | 6.0kw | |
| Air consumption | 50L/min 0.6Mpa | ||
| Electrical Data |
200-460V/50-60Hz/N+G (According to customer customization) |
||
Sample photo:
