Product Details:
|
Mix Type: | Homogenizer | Material Processed: | Chemicals, Food, Medicine |
---|---|---|---|
Product Type: | Cosmetic,Cream, Shampoo,Gel, Soap | Range Of Spindle Speed(r.p.m): | 0 - 60 R.p.m |
Application: | Viscous Fluid | Voltage: | 220V/380V 50HZ |
Function: | Vacuum Emulsifying Mixer | Applicable Industries: | Manufacturing Plant, Food & Beverage Factory, Cosmetics |
Highlight: | Double Jacket emulsifying mixer,Electric Heating emulsifying mixer,Cosmetic Cream Lotion vacuum emulsifier |
1. Performance and Characteristics
The equipment is suitable for emulsification of the pharmaceutical. Cosmetic, fine chemical products, especially the material having high matrix viscosity and solid content. Such as cosmetic, cream, ointment, detergent, salad, sauce,lotion, shampoo, toothpaste and so on.
2. Structure
The equipment consists of emulsifying pot, emulsifying system, stirring system, temperature control system, cooling system, heating system, safety system and pipeline, valve and so on.
3. Main Technical Parameters
Model | 50 |
Tank volume | 70L |
Working volume | 50L |
Pressure in tank | ≤0.1Mpa |
Jacket pressure |
≤0.1Mpa |
Type of heating and cooling | Electrical heating and Water cooling |
Fram agitator | 0--60 rpm 0.75kw |
High speed homogenizer | 0-2800 rpm 2.2kw |
Vacuum pump (Option) | -0.09Mpa |
