Product Details:
|
| Carton Gram Requirements: | 300-350g/m3 | Air Consumption: | 120-160L/min |
|---|---|---|---|
| Function: | Carton Forming | Key Word: | Automatic Cartoning Machine |
| Box Dimension Range: | (100-180) Mm× (30-70) Mm× (25-45) Mm | Machine Noise: | ≤80dB |
| Working Speed: | 30-80 Boxes/min | Power: | 1.5Kw |
| High Light: | Stainless Steel Wet Wipes Packing Machinery,50mm Length Wet Wipes Packing Machinery |
||
The machine is a new model developed by our company combining advanced technology at home and abroad. It’s a high-tech product integrating light, electricity, gas and machinery, greatly improving the performance and working efficiency, realizing the requirement of fast packing, and keeping stable and reliable state when running fast.
This machine is suitable for automatic feeding and packing of food, medicine, daily chemicals, entertainment, hardware and other goods. The automatic feeding mechanism is easy to adjust, the number of boxes to be packed can be set arbitrarily on the operation screen. The whole process of on-line material testing, indentation batch number, paper tongue packaging at both ends of paper box (also applicable to hot melt adhesive), material shortage elimination and finished product output is completed automatically.
| Cartoning speed | 30-80 cartons/ min | |
| Carton | Weight requirements | 300-350g/㎡ (depend on the size of the carton) |
| Dimension range (L×W×H) | (100-180) mm× (30-70) mm× (25-45) mm | |
|
Leaflet (optional) |
Weight requirements | 60-70 g/㎡ |
| Unfolded size range (L×W) | (80-250)㎜×(90-170)㎜ | |
| Folding range (L×W) | 1-4 (Fold) | |
| Compressed air | Working pressure | ≥0.6mpa |
| Air consumption | 120-160L/min | |
| Power supply | 380V 50HZ | |
| Main motor power | 1.5kw | |
| Dimension (L×W×H) | 3100mm×1100mm×1550mm | |
| Machine net weight | About 1400kg | |
1.what's the delivery time?
It's usually about 30 days
2.how many container request for this machine
Suggest ship by LCL.
3.Are you a manufacturer?
Yes,We have been packaging machinery over 17 years.
4.what about the payment term ?
Mostly 40%T/T in advanced,the rest need paid before shipping.
5.what's your advantages ?
--17 years experience:We have been in making machinery for 17 years.
--Customers all over the world
--Certificate: CE certificate
--Fast reply:Our team will reply you soon.
--After-sale service:We have a after sale department , service for your problems and dealing with spare parts.
