Product Details:
|
| Product Name: | Wet Wipes Folding Machine | Packing Material: | Heat Sealable PET, OPP,BOPP /AL/ PE, CPP Laminate Film |
|---|---|---|---|
| Marketing Typep: | Wet Wipes Products Making Machine | Key Word: | Wet Tissue Packing Machine |
| Usage: | Refreshing Wet Tissue Packing Machine | Pack: | Single Pack Wipes Packing Machine |
| After-warrantyrtService: | Video/Online Technical Support | Folding Way: | Max 10 Folding Vertical, And 4 Folding Horizontal |
| High Light: | CPP Film Wet Wipes Machine,Folding Wet Wipes Machine 130bags/Min,50mm Packing Wet Wipes Machine |
||
Fully Automatic Alcohol Packaing Production Equipment Non Woven Cloth Feedign
1, The machine work steadily and continiously, It is suitable for four-side sealing products of all types wet wipes/tissue, alcohol swabs/pad etc.
2, Single bag or two bags in row can be setted freely (Max four bags in row for alcohol swabs).
3, Full automatic pouch forming, photo electricity correction, no blank edge and fault forming
4, The tissue can be folded in different types. max 8 folding vertical, and 4 folding horizontal, fold freely by unfold nonwoven width, length.
5, Adopts Japan imported spray pump, make it accurate adding with tolerance of 0.01ml/time. Multical kinds of liquid are available. it can add per liquid per bag or add all the liquid in the same bag
6, Double times sealing better to ensure the liquid adding volume and avoid leaking.
7, The machine is easy to operate, PLC touch panel, could adjust the packing temperature and speed according to the packing material,product's thickness and length. servo motor. controlled by light, electric and air power, failures can be self- diagnosised and displays clearly.
8, The full machine is covered with Stainless steel in good appearance, also easy to clear and durable. Low operation and maintenance cost.
9, The Confined glass cover, to avoid contamination , less noise !
10, The Sealing molds is made by aluminum alloy , have a very high thermal shock resistance, do not thermal deformation.
| Item/model | Model:VPD250-B wet tissue packing machine |
| Packaging form | Horizontal Four-side sealing/ three side sealing |
| Packing specification | Length: 50mm-125mm width:50mm -110mm |
| Wrapping materials | Heat sealable PET, OPP,BOPP /AL/ PE, CPP laminate film |
| Max.ext. dia & Int.diameter | Max exterior diameter of film 350mm , Internal diameter 75mm |
| Wet Tissue Material | non-woven, spun lace non-woven fabric etc |
| Folding way | Max 10 folding vertical, and 4 folding horizontal |
| Inner size(unfold tissue) | Length: 40mm-220mm width:30mm -240mm |
| Packing speed | 80-130 bags/min |
| Liquid added range | 0-10ml [precision ±0.5ml ;the coefficient of viscosity should under the 20000(cp)] |
| Control panel | Colour touch-screen (Language On request) |
| Machine dimensions | L2800×W2800×H1800mm |
| Machine weight | 1200Kg |
| Package size | Plywood cases 3160*1080*1900mm |
| Power supply type | Single phase 2 wires 220V/ 3 phase four wires 380V 50/60Hz |
