Home ProductsAutomatic Facial Mask Making Machine

Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min

Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min

Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min
Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min
Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min
Product Details:
Place of Origin: CHINA
Brand Name: VIROO
Certification: CE
Model Number: VPD-98III
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: WOODEN CASE
Delivery Time: 90DAYS
Payment Terms: L/C, T/T
Supply Ability: 20sets/mon
Contact Now
Detailed Product Description
Wrapping Materials: Heat Sealable PET, OPP,BOPP /AL/ PE, CPP Laminate Film Mask Material: 30~80g/m2 Spun Non-woven/pearl Film/hot Roll Non-woven/silk
Unfolded Mask Size: Length 230~260mm Width 230~260mm Packing Speed: 80-100 Bags/min
Liquid Range: Essence Fluid 0-58ml; Precision ±1% Injection Heads: 3 Heads For Mask Essence
Voltage: 3phases 4 Wires 380V 50/60Hz Pre-made Bag Size: Length:140mm~220mm Width:110mm-180mm
High Light:

Multiple Head Facial Mask Packing Machine

,

100 Bags/Min Facial Mask Packing Machine

,

80Bags/Min Facial Mask Packing Machine

The high speed face mask packing machine is used for Prefabricated bag, adjustable bag chargers can use all kinds of special shaped bags flexibly, 3 injection heads can be independent used for Various of essence. The movable control panel operate the machine more comfortably.



Main Technical Parameter:



Pre-made bag size Length:140mm~220mm × Width:110mm-180mm (L*W)
Wrapping materials Heat sealable PET, OPP,BOPP /AL/ PE, CPP laminate film.
Mask material 30~80g/m2 Spun Non-woven/pearl film/hot roll non-woven/silk
Die-cut(Mask shape) Customized design (notice: manufacture only 1 layer mask, the gram per square metre of Non-woven have to above 45 g/m2 )
Max.ext. dia & Int.diameter max exterior diameter 1000mm Internal diameter 75mm ;
Automatic material roll splicer Standard no including (On request)
Unfolded Mask size Length 230~260mm width 230~260mm
Folding way On request
Packing speed 80-100 bags/min
Liquid range Essence Fluid 0-58ml; precision ±1%;the coefficient of viscosity should under the 20000(cp)
Injection heads 3 heads for mask essence;
Noise <70 dB(A) [closed safety door, lnstall the fans into another room]
Voltage 3phases 4 wires 380V 50/60Hz
Installed power AC 35Kw
Machine finishing Stainless Steel
Control panel Colour touch-screen (Language On request)
Air consumption ≥1.5m³/min(w-1.0/10 air compression machine is needed)
Air supply 0.6-1.0 MPa
Machine weight About 9000Kg
Machine size 11400mm×3160mm×2230mm







Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min 0Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min 1





Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min 2



Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min 3



Multiple Head Facial Mask Packing Machine Full Automatic 80-100 Bags/Min 4
